3-02 Min. Reference
Range:
Function:
[-4999 - 4999]
Sets limits for set-point and feedback.
3-03 Max. Reference
Range:
Function:
[-4999 - 4999]
Sets limits for set-point and feedback.
3-10 Preset Reference
Range:
Function:
[-100.00 - 100.00]
Preset [0] works as set-point.
4-12 Motor Speed Low Limit
Range:
Function:
[0.0 - 400 Hz]
Lowest possible output frequency.
4-14 Motor Speed High Limit
Range:
Function:
[0.0 - 400.00 Hz]
Highest possible output frequency.
6-22 Terminal 60 Low Current
Range:
Function:
[0.00 - 19.99 mA]
Normally set to 0 or 4 mA.
6-23 Terminal 60 High Current
Range:
Function:
[0.01 - 20.00 mA]
Normally (default) set to 20 mA.
6-24 Terminal 60 Low Feedback Value
Range:
Function:
[-4999 - 4999]
Value corresponding to P. 6-22 setting.
6-25 Terminal 60 High Feedback Value
Range:
Function:
[-4999 - 4999]
Value corresponding to P. 6-23 setting.
6-26 Terminal 60 Filter Time Constant
Range:
Function:
[0.01 - 10.00 s]
Filter for suppressing electrical noise.
7-20 Process CL Feedback Resource
Range:
Function:
[]
Choose [2] analog input 60.
7-30 Process PI Normal/Inverse
Range:
Function:
[]
Most PI controllers are “Normal”.
7-31 Process PI Anti Windup
Range:
Function:
[]
Leave Enabled normally.
7-32 Process PI Start Speed
Range:
Function:
[0.0 - 200.0 Hz]
Choose expected normal running speed.
