3 Electrical Installation
3.1 How to Connect
3.1.1 Electrical Installation in General
NB!
All cabling must comply with national and local regulations on cable cross-sections and ambient temperature. Copper conductors required, (60-75 ° C) recom-
mended.
Details of terminal tightening torques.
Power (kW) Torque (Nm)
Unit Size 1 x 200-240 V 3 x 200-240 V 3 x 380-480 V Line Motor DC connection/Brake Control Terminals Earth Relay
M1 0.18 - 0.75 0.25 - 0.75 0.37 - 0.75 1.4 0.7 Spade 1) 0.15 3 0.5
M2 1.5 1.5 1.5 - 2.2 1.4 0.7 Spade 1) 0.15 3 0.5
M3 2.2 2.2 - 3.7 3.0 - 7.5 1.4 0.7 Spade 1) 0.15 3 0.5
M4 11.0-15.0 1.3 1.3 1.3 0.15 3 0.5
M5 18.5-22.0 1.3 1.3 1.3 0.15 3 0.5
1) Spade connectors (6.3 mm Faston plugs)
Table 3.1: Tightening of terminals.
AF-60 LP™ Micro Drive Operating Instructions
DET-579A
