April 11, 2013 EBVW017A0S14R0 Series Power Modules; DC-DC Converters
36-75V
dc
Input; 14.0V
dc
Output; 17A Output Current
LINEAGE POWER 4
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions. See Feature Descriptions for additional information.
Parameter Device Symbol Min Typ Max Unit
Remote On/Off Signal Interface
(V
IN
=V
IN, min
to V
IN, max
, Signal referenced to V
IN-
terminal)
Negative Logic: device code suffix “1”
Logic Low = module On, Logic High = module Off
Positive Logic: No device code suffix required
Logic Low = module Off, Logic High = module On
Logic Low Specification
On/Off Thresholds:
Remote On/Off Current – Logic Low All I
on/off
280  310 μA
Logic Low Voltage All V
on/off
-0.3  0.8 V
dc
Logic High Voltage – (Typ = Open Collector) All V
on/off
2.0  14.5 V
dc
Logic High maximum allowable leakage current
(V
on/off
= 2.0V)
All I
on/off
  10 μA
Maximum voltage allowed on On/Off pin All V
on/off
  14.5 V
dc
Turn-on Delay and Rise Time (I
O
=I
O, max
)
T
delay
=Time until V
O
= 10% of V
O,set
from either
application of Vin with Remote On/Off set to On
(Enable with Vin); or operation of Remote On/Off
from Off to On with Vin already applied for at least
150 milli-seconds (Enable with on/off). All
T
delay, Enable
with Vin
  160 ms
All
T
delay
,
Enable
with on/off
  40 ms
T
rise
=Time for V
O
to rise from 10% to 90% of V
O,set
,
For C
O
>5000uF, I
O
must be < 50% I
O, max
during
T
rise
.
All T
rise
  40 ms
Prebias Output Load Performance:
Back Bias current sunk by output during start-up
Back Bias current sunk by output during shut-down
All 
 
 50
50 mA
mA
Output Overvoltage Protection All V
O,limit
17.0 V
dc
Overtemperature Protection
All T
ref
 140  °C
(See Feature Descriptions)
Input Undervoltage Lockout
Turn-on Threshold  35 36 V
dc
Turn-off Threshold 32 33.5  V
dc
Input Overvoltage Lockout
Turn-off Threshold  85 86 V
dc
Turn-on Threshold 76 79  V
dc
