Data Sheet
April 11, 2013 EBVW017A0S14R0 Series Power Modules; DC-DC Converters
36-75V
dc
Input; 14.0V
dc
Output; 17A Output Current
LINEAGE POWER 2
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are absolute
stress ratings only, functional operation of the device is not implied at these or any other conditions in excess of those
given in the operations sections of the Data Sheet. Exposure to absolute maximum ratings for extended periods can
adversely affect device reliability.
Parameter Device Symbol Min Max Unit
Input Voltage*
Continuous V
IN
-0.3 75 V
dc
Operating transient ≤ 100mS 100 V
dc
Operating Input transient slew rate, 50V
IN
to 75V
IN
(Output may exceed regulation limits, no protective
shutdowns shall activate, C
O
=220μF to C
O, max
)
- - 10 V/µs
Non- operating continuous V
IN
80 100 V
dc
Operating Ambient Temperature All T
A
-40 85 °C
(See Thermal Considerations section)
Storage Temperature All T
stg
-55 125 °C
I/O Isolation Voltage (100% factory Hi-Pot tested) All   2250 V
dc
* Input over voltage protection will shutdown the output voltage, when the input voltage exceeds threshold level.
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Parameter Device Symbol Min Typ Max Unit
Operating Input Voltage V
IN
36 48 75 V
dc
Maximum Input Current
I
IN,max
- - 7 A
dc
(V
IN
=0V to 75V, I
O
=I
O, max
)
Input No Load Current
All I
IN,No load
50 mA
(V
IN
= V
IN, nom
, I
O
= 0, module enabled)
Input Stand-by Current
All I
IN,stand-by
25 mA
(V
IN
= V
IN, nom
, module disabled)
External Input Capacitance All 100 - - μF
Inrush Transient All I 2 t - - 1 A 2 s
Input Terminal Ripple Current
(Measured at module input pin with maximum
specified input capacitance and
൏ 500uH inductance
between voltage source and input capacitance
C
IN
=220uF, 5Hz to 20MHz, V
IN
= 48V, I
O
= I
Omax
)
All - 900 - mA
rms
Input Reflected Ripple Current, peak-to-peak
(5Hz to 20MHz, 12μH source impedance; V
IN
= 48V,
I
O
= I
Omax
; see Figure 12)
All - 24 - mA
p-p
Input Ripple Rejection (120Hz) All - 50 - dB
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This power module can be used in a wide variety of applications, ranging from simple standalone operation to an
integrated part of sophisticated power architecture. To preserve maximum flexibility, internal fusing is not included,
however, to achieve maximum safety and system protection, always use an input line fuse. The safety agencies require a
fast-acting fuse with a maximum rating of 15 A (see Safety Considerations section). Based on the information provided in
this Data Sheet on inrush energy and maximum dc input current, the same type of fuse with a lower rating can be used.
Refer to the fuse manufacturer’s Data Sheet for further information.
