ProBee-ZE20S-HAxx User Guide Rev 1.9 36
5 Working with Development Kit
The ZE20S development kit provides a quick and easy way to be familiar with the ZE20S and test its
functionalities before you build your own PCB board to carry the ZE20S. It is always recommended to
start with the ZE20S development kit before your own design.
5.1 Development Kit Contents
The development kit consists of ZE20S modules and development boards to carry them. The
development board provides RS232 and USB interface to interface with computers and/or your target
devices. It provides terminals for digital inputs/outputs and analog inputs, too. It also provides on/off
switches and LEDs to simulate and verify digital inputs/outputs. In addition, it has temperature and light
sensor so you can test more practical applications. Below is the list of the items included in the package.
 ProBee ZE20S ZigBee OEM Module w/ Chip Antenna (ProBee-ZE20SDC) (1)
 ProBee ZE20S ZigBee OEM Module w/ U.FL Connector (ProBee-ZE20SDU) (1)
 ProBee ZE20S ZigBee OEM Module w/ RPSMA Connector (ProBee-ZE20SDS) (1)
 3 dBi Dipole Antenna, RP-SMA Plug, Right-hand Thread (2)
 12cm U.FL to RPSMA Cable, Right-Hand Thread (1)
 Development Boards (3)
 DC Power Adapters (3)
 RS232 Serial Cable (3)
 USB Cable (3)
5.2 Development Board Features
The development board is designed to provide convenient access to the ZE20S interface pins. The
development board provides external interfaces as below. Also Figure 5-1 shows the layout of those
interfaces of the development board.
 RS232 Interface
 USB Interface
 3 Pre-defined Digital Inputs: Hardware Reset, Factory Default Reset, Permit Joining
 8 User Configurable Digital Input Buttons
 8 Digital Outputs with LEDs (Active High)
 4 Analog Inputs
 Temperature Sensor
 Light Sensor
