ProBee-ZE20S-HAxx User Guide Rev 1.9
11
Working Distance: 300 m (0.19 miles) @ 3.3V, +5dBi Dipole Antenna
Various Antenna/Connector Options: Dipole 1/3/5dBi, U.FL, RPSMA, Chip
UART Signals Support: UART_TXD/RXD, RTS/CTS, DTR/DSR
6 Analog Inputs
17 Digital Inputs/Outputs
RoHS Compliant
Applications
Advanced Metering Infrastructure
Home Area Networks (HAN)
Neighborhood Area Networks (NAN)
Home Automation
Advanced lighting, entertainment and climate control systems
Service-based monitoring, security and awareness systems
Commercial Building Automation
Climate & lighting control systems
Industrial and Domestic Applications
1.3
ZigBee Home Automation Profile
ZigBee Home Automation Profile defines device descriptions and standard practices for applications
commonly found in a residential or light commercial environment. Installation scenarios range from a
single room to an entire home. The key applications included in this profile are lighting, HVAC, window
shades and security.
ZigBee Home Automation Profile provides standard interfaces and device definitions to allow inter
operability among ZigBee Home Automation devices produced by various manufacturers.
1.4
Home Automation Definitions
1.4.1
Cluster
Cluster is a container for one or more attributes and/or messages in a command structure. And Cluster is
a related collection of attributes and commands, which together define a communications interface
between two devices. The devices implement server and client sides of the interface respectively.
1.4.2
Attribute
Attribute is a data entity which represents a physical quantity or state. This data is communicated to other
devices using commands.
1.4.3
Cluster identifier
Cluster identifier is a reference to the unique enumeration of clusters within a specific application profile.
The cluster identifier is a 16-bit number unique within the scope of the application profile and identifies a
specific cluster. Cluster identifiers are designated as inputs or outputs in the simple descriptor for use in
