11
Route Mode
Routing
Protocol
Entry Operates Exit
RIP Routing
Protocol
Type router rip
command under Global
Mode.
Configure RIP
protocol parameters.
Use the exit
command to return to
Global Mode.
OSPF Routing
Protocol
Type router ospf
command under Global
Mode.
Configure OSPF
protocol parameters.
Use the exit
command to return to
Global Mode.
BGP Routing
Protocol
Type router bgp
mumber> command
under Global Mode.
Configure BGP
protocol parameters.
Use the exit
command to return to
Global Mode.
ACL Mode
ACL type Entry Operates Exit
Standard IP
ACL Mode
Type ip access-list
standard command
under Global Mode.
Configure parameters
for Standard IP ACL
Mode.
Use the exit command
to return to Global
Mode.
Extended IP
ACL Mode
Type ip access-list
extanded command
under Global Mode.
Configure parameters
for Extended IP ACL
Mode.
Use the exit command
to return to Global
Mode.
1.2.2 Configuration Syntax
Switch provides various configuration commands. Although all the commands are different,
they all abide by the syntax for Switch configuration commands. The general commands
format of Switch is shown below:
cmdtxt
{enum1 | … | enumN } [option1 | … | optionN]
Conventions: cmdtxt in bold font indicates a command keyword; indicates a
variable parameter;
{enum1 | … | enumN } indicates a mandatory parameter that should be
selected from the parameter set enum1~enumN; and the square bracket ([ ]) in [option1 | … |
optionN] indicate an optional parameter. There may be combinations of “< >“, “{ }” and “[ ]” in
the command line, such as [], {enum1 | enum2}, [option1 [option2]],
etc.
Here are examples for some actual configuration commands:
show version, no parameters required. This is a command with only a keyword and no
parameter, just type in the command to run.
vlan , parameter values are required after the keyword.
