Chapter 22 Layer 3 Management Configuration
Switch only support Layer 2 forwarding, but can configure a Layer 3 management port for the
communication of all kinds of management protocols based on IP protocol.
22.1 Layer 3 Management Interface
22.1.1 Introduction to Layer 3 Management Interface
Only one layer 3 management interface can be created on switch. The Layer 3 interface is not
a physical interface but a virtual interface. Layer 3 interface is built on VLANs. The Layer 3
interface can contain one or more layer 2 ports which belong to the same VLAN, or contain no
layer 2 ports. At least one of the Layer 2 ports contained in Layer 3 interface should be in UP
state for Layer 3 interface in UP state, otherwise, Layer 3 interface will be in DOWN state. The
switch can use the IP addresses set in the layer 3 management interface to communicate with
the other devices via IP.
22.1.2 Layer 3 Interface Configuration Task List
Layer 3 Interface Configuration Task List:
1. Create Layer 3 management interface
2. Configure VLAN interface description
1. Create Layer 3 Management Interface
Command Explanation
Global Mode
interface vlan
no interface vlan
Creates a management VLAN interface; the no command
deletes the VLAN interface created in the switch.
2. Configure VLAN interface description
Command Explanation
VLAN Interface Mode
description
no description
Configure the description information of VLAN interface.
The no command will cancel the description information
of VLAN interface.
