Powersolve HPW02401 Series User Manual
Short specification
Powersolve Electronics Ltd., Unit 8A Arnhem Road, Newbury RG14 5RU, United Kingdom
Tel 0044 (0)1635 521858 Fax 0044 (0)1635 523771
www.powersolve.co.uk
p.1/4 03.12B
(Subject to alterations. This product is not designed to be used in applications such as life support systems wherein a failure or malfunction could result in injury or death)
HPW02401 DIN Rail
Made in Germany
240W (312W) Power Supply -25...+70°C
85..264Vac active PFC & low inrush current
Short Specification:
•
Metal housing
•
91.5% efficiency
•
-25°C...+70°C ambient
•
Free air convection
•
Galvanic insulated
•
Continuous short circuit protected
•
Overload & low voltage protected
•
Soft start & auto-recovery
•
Hold up time >40ms
•
Minimum load = 0A
•
Electronic Inrush Current Limiter <7A
•
EMI/EMS EN61000-6-2/3, EN55022 class B
•
Active PFC: EN61000-3-2
•
According to cUL60950, IEC(EN)60950-1
•
Low voltage & overload control message
•
Remote ON/OFF
•
DIN Rail 35mm
•
Screw terminals AWG20...AWG12
•
High reliability, shock & vibration resistant
•
Output Electrolytic Capacitors +125°C
Smart start-up with critical loads:
-
motor drives
-
capacitive loads
-
DC-DC-converters
-
Batteries
Single-Out: 9...18V, 18...30V, 30...43V,
43...53V, 53...72V, 68...86V
In accordance with IEC60950-1
