Single Outputs
Total Power

Output (Volts/Amps)

Size (Inches)

Model Number

360W

2 / 180

2.5 x 5 x 10

MP4-3A-2A-30

400W

5 / 80

2.5 x 5 x 10

MP4-3E-00 - 429

600W

2 / 275

2.5 x 8 x 11

MP6-3A-3A-1A-90

600W

5 / 120

2.5 x 5 x 11

MP6-3E-00

600W

48 / 12.5

2.5 x 5 x 11

MP6-3W-00

800W

5 / 160

2.5 x 7 x 10

MP8-3E-2E-30 - 415

800W

48 / 16.6

2.5 x 7 x 10

MP8-3W-1W-30

1000W

5 / 200

2.5 x 8 x 11

MP1-3E-3E-30 - 404

Multiple Outputs
Total Power

Output 1

Output 2

Output 3

Output 4

Output 5

Output 6

Size

Model Number

(Volts/Amps)

(Inches)

400W

5 / 60

3.3 / 35

12 / 1

—

2.5 x 5 x 10

MP4-2E-1D-LLL-00

400W

24 / 15

12 / 17

5 / 35

—

2.5 x 5 x 10

MP4-2Q-1L-1E-00

400W

5 / 60

12 / 17

12 / 10

5 / 10

—

2.5 x 5 x 10

MP4-2E-1L-4LE-00

400W

5 / 35

12 / 10

3.3 / 10

12 / 1

5 / 2

2.5 x 5 x 10

MP4-1E-4LD-LLE-00

600W

3 / 60

5 / 60

12 / 10

12 / 4

—

2.5 x 5 x 11

MP6-2C-2E-4LL-00

600W

5 / 120

12 / 17

12 / 10

5 / 10

—

2.5 x 5 x 11

MP6-3E-1L-4LE-00

600W

12 / 30

5 / 35

—

2.5 x 5 x 11

MP6-2L-1E-00

800W

36 / 16.6

24 / 4

5 / 10

12 / 10

12 / 4

—

2.5 x 7 x 10

MP8-3U-4QE-4LL-00

800W

5 / 120

3.3 / 35

12 / 17

12 / 10

12 / 4

—

2.5 x 7 x 10

MP8-3E-1D-1L-4LL-00

800W

15 / 20

5 / 35

15 / 14

24 / 8.5

15 / 8

5 / 10

2.5 x 7 x 10

MP8-2N-1E-1N-1Q-4NE-00

800W

2 / 180

5 / 60

—

2.5 x 7 x 10

MP8-3A-2A-2E-30

1000W

3.3 / 120

5 / 120

—

2.5 x 8 x 11

MP1-3D-3E-00
