ESD141 60003098 1 1 1 1 1 1 1
SECOND BRAKE CONTACTOR
K71 Contactor LC1-D09D7 52303564 42VAC 1
C01E7 52296542 48VAC 1
C01F7 52296548 115VAC 1
LC1-D09P7 52296643 230VAC 1
RC-filter LA4-DA1E 52275256 42/48VAC 1
LA4-DA1U 52275257 115/230VAC 1
Auxliary contact LAD-8N20 52297562 1
LAD-N04 52297548 1
COMPONENTS FOR EMC LEVEL (N)
CM1 Y-capacitor KC-307-00 52298693 42VAC 1 1 1 1 1 1 1 1 1 1 1 1 1
Z1 Ferrite RU2100-30-7 52299351 Emission level N 1 1 1 1 1 1
Z2 RH175285107 52297604 1 1 1 1 1 1
Z3 RH175285107 52297604 1 1 1 1 1 1
Z1 EF32010 52299352 2 2 2
Z2 W74270096 52299353 1 1 1
Z3 W7427015 52299354 2 2 2
Z1 EF32010 52299352 2 2 2
Z2 W7427015 52299354 1 1 1
Z3 W742701111 52300355 7 7 7
Z2 W7427015 52299354 3
Z3 W7427015 52299354 4
