MWh Counter
T6.8.2.1.
MWh counter, can be reseted
Clr MWh Counter
P6.8.2.2.
Clear MWh counter T6.8.2.1.
Not reset / Reset
PwOn Day Counter
T6.8.2.3.
Number of power on days
PwOn hour count.
T6.8.2.4.
Number of power on hours
Clr Optime cntr
T6.8.2.5.
Clear trip counters T6.8.2.1. – T6.8.2.4.
S6.8.3. Software
Software package
I6.8.3.1.
See software sticker under display, IND3V114
NXP00002V182
SystemSw version
I6.8.3.2.
33.02.9431
Firmware interf.
I6.8.3.3.
4.64
System load
I6.8.3.4.
Load of CPU
%
S6.8.4. Applications
A6.8.4.1. Crane
Application id
D6.8.4.1.1.
See software sticker under display, IND3V114
Industr3
Version
D6.8.4.1.2.
See software sticker under display, IND3V114
11.40
Firmware interf.
D6.8.4.1.3.
4.62
S6.8.5. Hardware
Power unit
I6.8.5.1.
Power unit id code
Unit voltage
I6.8.5.2.
Nominal voltage of D2V
500V
Brake chopper
E6.8.5.3.
There is brake chopper in D2V
No
Brake resistor
E6.8.5.4.
No braking resistor inside D2V
No
Serial number
E6.8.5.5.
Serial number of CSU
S6.8.6. Expander boards
E6.8.6.1. A:NXOPTA6
State
E6.8.6.1.1.
State of board in slot A
Run
Program version
E6.8.6.1.2.
Program version of board in slot A
0.0
E6.8.6.2. B:NXOPTA3
State
E6.8.6.2.1.
State of board in slot B
Run
Program version
E6.8.6.2.2.
Program version of board in slot B
10005.0
E6.8.6.3. C:SSU
State
E6.8.6.3.1.
State of board in slot B
Run
Program version
E6.8.6.3.2.
Program version of board in slot B
10503.14
E6.8.6.4. D:NXOPTB9
State
E6.8.6.4.1.
State of board in slot B
Run
Program version
E6.8.6.4.2.
Program version of board in slot B
10501.4
E6.8.6.5. E: No board
S6.8.7. Debug
Not used
S6.9. Power monitor
IU filtered
V6.9.1.
U phase current
A
IV filtered
V6.9.2.
V phase current
A
IW filtered
V6.9.3.
W phase current
A
U Temperature
V6.9.4.
Phase U temperature
°
C
V Temperature
V6.9.5.
Phase V temperature
°
C
W Temperature
V6.9.6.
Phase W temperature
°
C
Card Temperature
V6.9.7.
Card temperature
°
C
S6.11 Power multimon.
Power multimonitor
V6.11.1.
Output current values and power card temperature
M7 Active faults
The memory of active faults can store the maximum of 10 faults in the
