G4.23 Multimonitor
Multimonitor N4.23.1. Multimonitor page shows motor current, motor voltage and putput
frequency in display in the same time. Monitor variables can be changed
if parameter P6.5.4. = ChangeEnable
G5 Panel Control
Panel Control B5.1. Must not be used. Off, On
Speed Reference R5.2. Speed reference for panel control
M6 System Menu
Language S6.1. Keypad language English
Application S6.2. Application Crane
S6.3. Copy Parameters
Parameter Sets S6.3.1. Not used, see parameter group G4.1. Parameter backup
Up to keypad S6.3.2. Save parameter settings up to keypad
Down from keypad S6.3.3. Download parameter settings down from keypad
Autom. BackUp P6.3.4. Changes in parameters are automatically saved to Keypad settings Yes / No
S6.4. ParamComparison
Set 1 S6.4.1. Actual parameter values are compared to Default parameters. Value of
parameters can also be changed in this display. Par. No. = Default val.
Actual value
Set 2 S6.4.2. Actual parameter values are compared to file User parameters. Value
of parameters can also be changed in this display. Par. No. = User val.
Actual value
Factory settings S6.4.3. Parameter file Factory settings is not used
Keypad set S6.4.4. Actual parameter values are compared to parameter file saved in
Keypad.
S6.5. Security
Password S6.5.1 Password for group S6.5.
Parameter lock P6.5.2 Not used Change Enable
Startup wizard P6.5.3. Not used No
Multimon. Items P6.5.4. Enables or disables chancing of variables in multimonitor page
N4.23.1. ChangeEnable
ChangeDisable
S6.6. Keypad settings
Default page P6.6.1. Default page to which the display automatically moves as the Timeout
time has expired or as the power is switched on to the keypad.
If the Default Page value is 0 the function is not activated, i.e. the last
displayed page remains on the keypad display.
Default page/OM P6.6.2.
Timeout time P6.6.3. The time after which the keypad display returns to default page.
Contrast P6.6.4. Display contrast.
Backlight time P6.6.5. Determines how long the backlight stays before going out. Value “0”
means Forever. 0 – 65535 min
S6.7. HW settings
InternBrake Res P6.7.1. Must not be changed. Not conn.
Fan Control P6.7.2. Must not be changed. First start
HMI ACK timeout P6.7.3 Not used
HMI retry P6.7.4. Not used
S6.8. System Info
S6.8.1. Total counters
MWh counter C6.8.1.1. MWh counter, can not be reseted
PwOn Day Counter C6.8.1.2. Total number of power on days
PwOn hour count. C6.8.1.3. Total number of power on hours
S6.8.2. Trip counters
