Group Table
Configure SNMP v3 group table.
 Security Name (User ID): Assign the user name that was set up in the
user table.
 Group Name: Enter the group name.
 Click
Add
 Click
Remove to remove an unwanted context name.
Access Table
Configure SNMP v3 access table.
 Context Prefix: Enter the context name.
 Group Name: Enter the group.
 Security Level: Enter the access level.
 Context Match Rule: Select the context match rule.
 Read View Name: Set up the read view.
 Write View Name: Set up the write view.
 Notify View Name: Set up the notify view.
 Click
Add
 Click
Remove to remove an unwanted context name.
MIBview Table
Configure MIB view table.
 ViewName: Set up the name.
 Sub-Oid Tree: Fill the Sub OID.
 Type: Select the type – exclude or included.
 Click
Add
 Click
Remove to remove an unwanted context name.
