2. Group ID: There are three trunk groups available to configure. Choose
the ‗Group ID‘ and click
Select .
3. LACP: If enabled, the group is an LACP static trunk group. If disabled,
the group is local static trunk group. All ports support LACP dynamic
trunk. If connected to a device that also supports LACP, the LACP
dynamic trunk group is automatically created.
4. Work ports: A maximum of four ports can be aggregated at the same
time. With LACP static trunk group, any excess ports are considered
standby and can be aggregated if a work port fails. If it is local static
trunk group, the number of ports must be the same as the group
member ports.
5. Select the ports add to the trunk group. Click Add button to add the
port. To remove unwanted ports, select the port and click Remove
button.
6. When LACP is enabled, you can configure LACP Active/Passive status
for each port on the State Activity page.
7. Click Apply .
8. Use Delete button to delete Trunk Group.
