System Information
 System Name: A name (64 bytes max) can be assigned to the switch.
 System Description: Displays the description of switch. Read only
cannot be modified
 System Location: A physical location (64 bytes max) can be assigned
to the switch.
 System Contact: Enter the name of contact person or organization
 Firmware Version: Displays the switch‘s firmware version
 Kernel Version: Displays the kernel software version
 MAC Address: Displays the unique hardware address assigned by
manufacturer (default)
IP Configuration
Configure the IP Settings and DHCP client function
 DHCP Client: Used to enable or disable the DHCP client function.
When enabled, the switch
‘s IP address is assigned by the network
DHCP server. The default IP address will be replace by the DHCP
server assigned IP address. After clicking the ‗Apply‘ button, a popup
dialog will indicate that the current IP will be lost and the new IP
address must be retrieved from the DHCP server.
 IP Address: A static IP Address may be assigned. The default IP is
192.168.16.1.
 Subnet Mask: Assign the subnet mask of the IP address. This does
not have to be done if the DHCP client function is enabled.
 Gateway: Assign the network gateway. The default gateway is
192.168.16.254.
 DNS1: Assign the primary DNS IP address.
 DNS2: Assign the secondary DNS IP address.
 Click
Apply
