42
2. Set Transparent Mode to allow both tagged data and untagged management
traffic to pass:
a. In the Main Configuration screen, press the Space Bar and type config. The
Configuration Screen displays:
b. Enter Y in the Transparent Mode field and press any key (except S or Q) to
open the Transparent Mode Setup screen.
c. Press S or F3 to save without setting any transparent mode options. This will
set all untagged traffic as management
.
d. Type Reboot. In this mode only tagged data will pass to the data port.
TRANSPARENT MODE SETUP
Is a VLAN tag required on Management packets? [ N ]
Do you want to enter the Extra Tag mode? Enter Y for Extra Tagging.
Enter N if you do not want Extra Tags [ N ]
Are VLAN Tags required on the EXT Port? [ N ]
Type S or F3 to save the new information
Type Q of F4 to quit and cancel changes
Reboot is required for any change to take affect.
Transparent Mode – with either (not both) Data and Optics Mgmt dipswitches
set to on, all traffic passes between Optics and Data port EXCEPT what has
been defined as the Management Domain. The Management Domain can either be
defined as untagged traffic or traffic with a specified VLAN ID.
In Transparent Mode with BOTH Optics and Data Mgmt dipswitches set to off,
all traffic passes between the Optics and Data Ports.
Default Mode – the unit passes only Untagged Packets.
The unit is currently
in Default Mode
.
Enter Y for Transparent Mode, N for no Transparent Mode or
move to other options [ Y ]
