Transparent Mode
The Transparent Mode screen is displayed when the iMcV-FiberLinX-II module is
configured in Default mode or Transparent mode.
Transparent Mode Setup Screen
When Transparent Mode is enabled, the next screen is the Transparent Mode Setup
screen:
The following parameters can be set in this screen:
• VLAN Tag on Management Packets
• Extra Tag Mode
• VLAN Tag on EXT MGMT port
Transparent Mode Setup
This parameter makes it possible to use all untagged data as the management domain
by entering N, or to define a VLAN ID tag for the management domain by entering Y.
When Y is entered, this field expands to display the Management Tag field and the
Management Priority field.
TRANSPARENT MODE SETUP
Is a VLAN tag required on Management packets? [ Y ]
The Management Tag is [7 ]
Management Priority is [0 ]
Do you want to enter the Extra Tag mode? Enter Y for Extra Tagging.
Enter N if you do not want Extra Tags [ N ]
Are VLAN Tags required on the EXT Port? [ N ]
Type S or F3 to save the new information
Type Q of F4 to quit and cancel changes
Reboot is required for any change to take affect.
TRANSPARENT MODE SETUP
Is a VLAN tag required on Management packets? [ N ]
Do you want to enter the Extra Tag mode? Enter Y for Extra Tagging.
Enter N if you do not want Extra Tags [ N ]
Are VLAN Tags required on the EXT Port? [ N ]
Type S or F3 to save the new information
Type Q of F4 to quit and cancel changes
Reboot is required for any change to take affect.
Transparent Mode – with either (not both) Data and Optics Mgmt dipswitches
set to on, all traffic passes between Optics and Data port EXCEPT what has
been defined as the Management Domain. The Management Domain can either be
defined as untagged traffic or traffic with a specified VLAN ID.
In Transparent Mode with BOTH Optics and Data Mgmt dipswitches set to off,
all traffic passes between the Optics and Data Ports.
Default Mode – the unit passes only Untagged Packets.
The unit is currently
in Default Mode
.
Enter Y for Transparent Mode, N for no Transparent Mode or
move to other options [ Y ]
