27
Clean Database—cleandb
There are two levels of cleandb: The first level resets the Telnet/iConfig password and
all of the SNMP database values. The second level additionally resets the IP address,
IP Subnet, Gateway, VLAN settings, CLI command settings, serial port password and
security settings.
Downloading Files—download
The iMcV-FiberLinX-II allows downloading firmware from a central server by using
TFTP. To download firmware by using either a serial connection or a Telnet session,
perform the following:
1. In the Main Configuration screen, enter the TFTP server IP Address and the name
of the Prom file to be downloaded (case sensitive).
2. Reboot the unit to make these settings current.
3. Press the Space Bar from the Command List section in the Main Configuration
screen. The Device-Specific Options screen displays.
4. Type download and press Enter. The Download a File screen displays with the IP
Address of the TFTP server and the name of the file to download. Confirm that
the server IP address and the filename are correct.
5. Press Enter. The release notes are displayed. Use the Space Bar to page through
the notes.
6. After reviewing the notes, enter Y to start downloading the file.
7. The download progress displays and ends with a successful download message or
with an error message.
8. Press Q or F4 to return to the Device-Specific Options screen.
When the iMcV-FiberLinX-II is installed in a managed chassis, it is possible to use
UMA to update the firmware (refer to the iView
2 online help for more information on
using UMA with iConfig, iMediaChassis and iMcV-FiberLinX-II).
Port Configuration—port
The iMcV-FiberLinX-II allows viewing port status and configuring some port features
from a serial connection or a Telnet session. In the Commands list, type port and
press Enter to access the Port Status/Control screen.
