Port VLAN Filter
This parameter allows passing traffic with up to 32 separate VLAN IDs between the
OPTICS (or UPLINK) port and the DATA port. To enable the Data VLANS fields,
enter Y in the Tags column for both the Optics and Data rows. Enter up to 32 VLAN
IDs in the Data VLANs fields; VLAN IDs can be any number between 1 and 4,094.
Unit Configuration—unit
The iMcV-Giga-FiberLinX-II allows viewing unit status as well as configure some unit
features by using a serial connection or a Telnet session. In the Main Configuration
screen, press the Space Bar, type unit, and press Enter to open the Unit Control
Settings screen. In this screen it is possible to view the unit FlowControl,
FiberAlert/LinkLoss, Loopback, Maximum Frame Size, and 802.1p Base Priority
(logging-in as a User in a Telnet session allows viewing these settings, but prevents
changing the settings).
Unit FlowControl –
This enables/disables Flow Control functionality on the unit, and
must be enabled to use Flow Control on any port. The settings include the following:
• Disable FlowControl Globally
• Enable FlowControl If Port Allows
------------------------- Unit Control Settings -----------------------------
Unit FlowControl
Disable FlowControl Globally
Unit FiberAlert
TXLinkLoss Plus FXLinkLoss Enabled
Unit LoopBack
No LoopBack, Normal Traffic Mode
Unit Max FrameSz
Oversized Frames:
1536
802.1p Base Pri
Base Priority 4
Brdcast Max Rate
Max Broadcast rate 1%
Use
Arrow Keys
To Move Cursor. Press
Space Bar
To Change Value.
Press
RETURN
To Set New Value. Type
Q
or
F4
to Exit.
Saved VLAN Values
VLAN IDs Priorities Tags
Current Saved Current Saved
Ports Data VLANs are used
only
Optics [0 ] [
0
] [0 ] [
0
] [
Y
] if Tags are enabled
on both
Data [0 ] [
0
] [0 ] [
0
] [
Y
] the Optics and Data
Ports.
Management VLAN EXT Mgmt Tag
SNMP [0 ] [
0
] [0 ] [
0
] [
N
]
Data VLANs
VLAN 1 [0 ] [
900
] VLAN 12 [0 ] [
911
] VLAN 23 [0 ] [
922
]
VLAN 2 [0 ] [
901
] VLAN 13 [0 ] [
912
] VLAN 24 [0 ] [
923
]
VLAN 3 [0 ] [
902
] VLAN 14 [0 ] [
913
] VLAN 25 [0 ] [
924
]
VLAN 4 [0 ] [
903
] VLAN 15 [0 ] [
914
] VLAN 26 [0 ] [
925
]
