18
Basic Device Configuration
After running through an initial self test, the screen will display the following message:
Press
screen:
This screen contains the following information and options:
Saved and Current Values
Saved values display the changes made during the current session and current values
display the values currently in use:
• IP Address (IP address of SNMP agent)
• Subnet Mask (mask to define IP subnet to which agent is connected)
• Default Gateway (default router for IP traffic outside of the subnet)
• Server IP Address (TFTP server)
• New Prom File (TFTP new file name)
Command List
I = Enter new Saved Parameter Values
P = Change the Password*
T = Enter new Trap Destinations
K = Remove All Trap Destinations
C = Create SNMP Community Strings
U = Delete All SNMP Community Strings
E = End the session*
Reboot = Reboot the unit (may result in short data loss)
D = Enable or disable DHCP
Space Bar = Opens the device specific configuration options screen.
* Individuals with User-level rights can only view port status and port settings, change
their password, end a session, and reboot the unit.
Saved Values.
IP Address -
10.10.10.10
Subnet Mask -
255.0.0.0 DHCP is not active
Default Gateway -
000.000.000.000
Server IP Addr -
000.000.000.000
New Prom File -
filename
Current Values.
IP Address -
10.10.10.10
Subnet Mask -
255.0.0.0
Default Gateway -
000.000.000.000
Server IP Addr -
000.000.000.000
New Prom File -
filename
Community String:
public
Access:
r/w
Press
I
to enter new saved parameter values. Press
P
to change Password.
Press
T
to enter new Trap Destination. Press
K
to remove
ALL
Trap Destinations.
Press
C
to enter new Community String. Press
U
to remove
ALL
Community Strings.
Press
E
to End session. Type
REBOOT
to reboot unit. Press
D
for
DHCP
On/Off.
Press
SpaceBar
for additional commands.
