27
Transparent with VLAN Tag on EXT MGMT Port
This parameter adds the management VLAN ID tag to all untagged data arriving at the
EXT MGMT port by entering N, or can restrict the EXT MGMT port to only accept
data tagged with the management VLAN ID by entering Y.
VLAN Mode Screen
When N is entered in the Transparent Mode Setup screen, the VLAN Mode screen
displays:
The following parameters can be set in this screen:
• Default Mode
• Port VLAN on OPTICS (or UPLINK) port
• Port VLAN on DATA port
• Management VLAN
• Port VLAN Filter
Saved VLAN Values
VLAN IDs Priorities Tags
Current Saved Current Saved
Ports Data VLANs are used only
Optics [0 ] [
0
] [0 ] [
0
] [
N
] if Tags are enabled on both
Data [0 ] [
0
] [0 ] [
0
] [
N
] the Optics and Data Ports.
Management VLAN EXT Mgmt Tag
SNMP [0 ] [
0
] [0 ] [
0
] [
N
]
Data Vlans
VLAN 1 [0 ] [
0
] VLAN 12 [0 ] [
0
] VLAN 23 [0 ] [
0
]
VLAN 2 [0 ] [
0
] VLAN 13 [0 ] [
0
] VLAN 24 [0 ] [
0
]
VLAN 3 [0 ] [
0
] VLAN 14 [0 ] [
0
] VLAN 25 [0 ] [
0
]
VLAN 4 [0 ] [
0
] VLAN 15 [0 ] [
0
] VLAN 26 [0 ] [
0
]
VLAN 5 [0 ] [
0
] VLAN 16 [0 ] [
0
] VLAN 27 [0 ] [
0
]
VLAN 6 [0 ] [
0
] VLAN 17 [0 ] [
0
] VLAN 28 [0 ] [
0
]
VLAN 7 [0 ] [
0
] VLAN 18 [0 ] [
0
] VLAN 29 [0 ] [
0
]
VLAN 8 [0 ] [
0
] VLAN 19 [0 ] [
0
] VLAN 30 [0 ] [
0
]
VLAN 9 [0 ] [
0
] VLAN 20 [0 ] [
0
] VLAN 31 [0 ] [
0
]
VLAN 10 [0 ] [
0
] VLAN 21 [0 ] [
0
] VLAN 32 [0 ] [
0
]
VLAN 11 [0 ] [
0
] VLAN 22 [0 ] [
0
]
Valid Vlan IDs are between 1 and 4094. Valid priorities are between 0 and 7.
Type S or F3 to save the changes. Type Q or F4 to quit and cancel changes.
TRANSPARENT MODE SETUP
Is a VLAN tag required on Management packets? [ Y ]
The Management Tag is [7 ]
Management Priority is [0 ]
Do you want to enter the Extra Tag mode? Enter Y for Extra Tagging.
Enter N if you do not want Extra Tags [ N ]
Are VLAN Tags required on the EXT Port? [ N ]
Type S or F3 to save the new information
Type Q of F4 to quit and cancel changes
Reboot is required for any change to take affect.
