MAX6960–MAX6963
4-Wire Serially Interfaced
8 x 8 Matrix Graphic LED Drivers
32 ______________________________________________________________________________________
MAX6960
ADDIN ADDOUT
MAX6960
ADDIN ADDOUT
MAX6960
ADDIN ADDOUT
3.3V
ANODE
ROWS
(DIGITS 0, 1)
CATHODE COLUMNS
DIGIT 0
RED
DIGIT 1
RED
ANODE
ROWS
(DIGITS 2, 3)
CATHODE COLUMNS
DIGIT 2
RED
DIGIT 3
RED
ANODE
ROWS
(DIGITS 4, 5)
CATHODE COLUMNS
DIGIT 4
RED
DIGIT 5
RED
TO NEXT MAX6960
MAX6960
ADDIN ADDOUT
MAX6960
ADDIN ADDOUT
MAX6960
ADDIN ADDOUT
3.3V
CATHODE COLUMNS
DIGIT 0
GREEN
DIGIT 1
GREEN
CATHODE COLUMNS
DIGIT 2
GREEN
DIGIT 3
GREEN
CATHODE COLUMNS
DIGIT 4
GREEN
DIGIT 5
GREEN
TO NEXT MAX6960
MAX6960
ADDIN ADDOUT
MAX6960
ADDIN ADDOUT
MAX6960
ADDIN ADDOUT
3.3V
CATHODE COLUMNS
DIGIT 0
BLUE
DIGIT 1
BLUE
CATHODE COLUMNS
DIGIT 2
BLUE
DIGIT 3
BLUE
CATHODE COLUMNS
DIGIT 4
BLUE
DIGIT 5
BLUE
TO NEXT MAX6960
ROW0–ROW8 COL0–COL8 COL9–COL16 ROW0–ROW8 COL0–COL8 COL9–COL16 ROW0–ROW8 COL0–COL8 COL9–COL16
ROW0–ROW8 COL0–COL8 COL9–COL16 ROW0–ROW8 COL0–COL8 COL9–COL16 ROW0–ROW8 COL0–COL8 COL9–COL16
ROW0–ROW8 COL0–COL8 COL9–COL16 ROW0–ROW8 COL0–COL8 COL9–COL16 ROW0–ROW8 COL0–COL8 COL9–COL16
Figure 17. Connecting MAX6960–MAX6963s to RGB Displays
