MAX8760

Dual-Phase, Quick-PWM Controller for AMD
Mobile Turion 64 CPU Core Power Supplies

8

_______________________________________________________________________________________

ELECTRICAL CHARACTERISTICS (continued)

(Circuit of Figure 1, V+ = 15V, V

CC

= V

DD

= V

SHDN

= V

SKIP

= V

S0

= V

S1

= 5V, V

FB

= V

CMP

= V

CMN

= V

CSP

= V

CSN

= 1.3V, OFS =

SUS = GNDS = D0–D5 = GND, T

A

= -40°C to +100°C, unless otherwise specified.) (Note 5)

PARAMETER

SYMBOL

CONDITIONS

MIN

MAX

UNITS

High state (pullup)

4.5

DL_ Gate-Driver On-Resistance

R

ON(DL)

Low start (pulldown)

2

VOLTAGE-POSITIONING AMPLIFIER

Input Offset Voltage

V

OS

-2.0

+2.0

mV

Common-Mode Input Voltage
Range

V

CM

Guaranteed by CMRR test

0

2.5

V

V

CC

- V

FBH

300

Output Voltage Swing

|V

OAIN+

- V

OAIN-

|

≥ 10mV,

R

L

= 1k

Ω to V

CC

/2

V

FBL

200

mV

LOGIC AND I/O

SHDN Input High Voltage

V

IH

0.8

V

SHDN Input Low Voltage

V

IL

0.4

V

High

2.7

REF

1.2

2.3

Tri-Level Input Logic Levels

SUS, SKIP

Low

0.8

V

D0–D5 Logic Input High Voltage

1.6

V

D0–D5 Logic Input Low Voltage

0.8

V

High

V

CC

-

0.4

Open

3.15

3.85

REF

1.65

2.35

Four-Level Input Logic Levels

TON, S0 and S1

Low

0.4

V

Note 2: DC output accuracy specifications refer to the trip level of the error amplifier. When pulse skipping, the output slightly rises

(<0.5%) when transitioning from continuous conduction to no load.

Note 3: On-time and minimum off-time specifications are measured from 50% to 50% at the DHM and DHS pins, with LX_ forced to

GND, BST_ forced to 5V, and a 500pF capacitor from DH_ to LX_ to simulate external MOSFET gate capacitance. Actual in-
circuit times may be different due to MOSFET switching speeds.

Note 4: The output fault-blanking time is measured from the time when FB reaches the regulation voltage set by the DAC code.

During normal operation (SUS = GND), the regulation voltage is set by the VID DAC inputs (D0–D5). During suspend mode
(SUS = REF or high), the regulation voltage is set by the suspend DAC inputs (S0 and S1).

Note 5: Specifications to T

A

= -40°C and +100°C are guaranteed by design and are not production tested.
