Power MOSFET Selection
Most of the following MOSFET guidelines focus on the
challenge of obtaining high load-current capability
when using high-voltage (>20V) AC adapters. Low-cur-
rent applications usually require less attention.
The high-side MOSFET (N
H
) must be able to dissipate
the resistive losses plus the switching losses at both
V
IN(MIN)
and V
IN(MAX)
. Calculate both of these sums.
Ideally, the losses at V
IN(MIN)
should be roughly equal to
losses at V
IN(MAX)
, with lower losses in between. If the
losses at V
IN(MIN)
are significantly higher than the losses
at V
IN(MAX)
, consider increasing the size of N
H
(reducing
R
DS(ON)
but with higher C
GATE
). Conversely, if the losses
at V
IN(MAX)
are significantly higher than the losses at
V
IN(MIN)
, consider reducing the size of N
H
(increasing
R
DS(ON)
to lower C
GATE
). If V
IN
does not vary over a wide
range, the minimum power dissipation occurs where the
resistive losses equal the switching losses.
Choose a low-side MOSFET that has the lowest possible
on-resistance (R
DS(ON)
), comes in a moderate-sized
package (i.e., one or two 8-pin SOs, DPAK, or D
2
PAK),
and is reasonably priced. Ensure that the DL gate driver
can supply sufficient current to support the gate charge
and the current injected into the parasitic gate-to-drain
capacitor caused by the high-side MOSFET turning on;
otherwise, cross-conduction problems can occur (see
the MOSFET Gate Driver section).
MOSFET Power Dissipation
Worst-case conduction losses occur at the duty factor
extremes. For the high-side MOSFET (N
H
), the worst-
case power dissipation due to resistance occurs at the
minimum input voltage:
where
η
TOTAL
is the total number of phases.
Generally, a small high-side MOSFET is desired to
reduce switching losses at high input voltages.
However, the R
DS(ON)
required to stay within package
power dissipation often limits how small the MOSFET
can be. Again, the optimum occurs when the switching
losses equal the conduction (R
DS(ON)
) losses. High-
side switching losses do not usually become an issue
until the input is greater than approximately 15V.
Calculating the power dissipation in high-side MOSFET
(N
H
) due to switching losses is difficult since it must
allow for difficult quantifying factors that influence the
turn-on and turn-off times. These factors include the
internal gate resistance, gate charge, threshold
voltage, source inductance, and PC board layout
characteristics. The following switching-loss calculation
provides only a very rough estimate and is no substi-
tute for breadboard evaluation, preferably including
verification using a thermocouple mounted on N
H
:
where C
RSS
is the reverse transfer capacitance of N
H
and I
GATE
is the peak gate-drive source/sink current
(1A typ).
Switching losses in the high-side MOSFET can become
an insidious heat problem when maximum AC adapter
voltages are applied due to the squared term in the C x
V
IN
2
x f
SW
switching-loss equation. If the high-side
MOSFET chosen for adequate R
DS(ON)
at low battery
voltages becomes extraordinarily hot when biased from
V
IN(MAX)
, consider choosing another MOSFET with
lower parasitic capacitance.
For the low-side MOSFET (N
L
), the worst-case power
dissipation always occurs at maximum input voltage:
The worst-case for MOSFET power dissipation occurs
under heavy overloads that are greater than
I
LOAD(MAX)
but are not quite high enough to exceed
the current limit and cause the fault latch to trip. To pro-
tect against this possibility, you can “overdesign” the
circuit to tolerate:
where I
VALLEY(MAX)
is the maximum valley current
allowed by the current-limit circuit, including threshold
tolerance and on-resistance variation. The MOSFETs
must have a good-size heatsink to handle the overload
power dissipation.
Choose a Schottky diode (D
L
) with a forward voltage
low enough to prevent the low-side MOSFET body
diode from turning on during the dead time. As a gen-
eral rule, select a diode with a DC current rating equal
to 1/3 of the load current-per-phase. This diode is
optional and can be removed if efficiency is not critical.
Boost Capacitors
The boost capacitors (C
BST
) must be selected large
enough to handle the gate-charging requirements of
the high-side MOSFETs. Typically, 0.1µF ceramic
capacitors work well for low-power applications driving
I
I
I
I
I
LIR
LOAD
TOTAL
VALLEY MAX
INDUCTOR
TOTAL VALLEY MAX
LOAD MAX
=
+
=
+
η
η
(
)
(
)
(
)
∆
2
2
PD N RESISTIVE
V
V
I
R
L
OUT
IN MAX
LOAD
TOTAL
DS ON
(
)
(
)
(
)
=
−
1
2
η
PD N
SWITCHING
V
C
f
I
I
H
IN MAX
RSS SW
GATE
LOAD
TOTAL
(
)
(
)
(
)
=
2
η
PD N
RESISTIVE
V
V
I
R
H
OUT
IN
LOAD
TOTAL
DS ON
(
)
(
)
=
η
2
