Basic operation
English Manual 17
Basic operation
Introduction
This section of the manual is a general introduc-
tion to operating UpCon using the TC Icon soft-
ware.
In the following chapters we assume that you
have connected UpCon and your computer di-
rectly or as part of a network as described in
“Setting up UpCon” on page 13.
Several UpCon and other TC signal processors
(e.g. DB4/DB8 MKII), and computers running the
TC Icon software can be connected and oper-
ated at the same time as part of a standard Lo-
cal Area Network (LAN). The TC Icon software is
used to detect, configure and operate devices
from your computer.
If you encounter communication errors or cannot
detect or operate a device properly, please refer
to “Networking basics and troubleshooting” on
page 13.
Basic TC Icon operation
The TC Icon software interface has been opti-
mized for use in real-time situations in broadcast
and post production environments (which usual-
ly are very different from standard desktop com-
puting tasks and environments). Accordingly,
buttons are very prominent and clearly labelled
to ensure proper operation even in stressful situ-
ations. In addition, important parameters can be
assigned to on-screen
faders, allowing for pre-
cise control and immediate visual feedback.
The interface can be customized. Customizable
parameters include fader positions and user in-
terface colors. For more information, please refer
to the chapters ““UI page” on page 34” and
“Color page” on page 34 of this manual.
TC Icon interface: Tabs versus pages
– Use the tab buttons on the upper edge of the
TC Icon window to select a primary group of
functions.
– Use the page buttons on the left edge of the
TC Icon window to select specific pages.
TC Icon modes: Base and
Device operation
The TC Icon software has two operation modes:
Base and Device operation.
– Use Base mode to select devices and con-
figure the network and the TC Icon software
itself.
In Base mode, you will see the Select, Auto
and Setup tabs on the upper edge of the TC
Icon window. Most Base mode functions are
described in the chapter “Icon Setup” on page
33.
– Use Device operation mode to operate the
currently selected device.
In Device Mode, you will see the specific tabs
for operating the currently selected TC device.
Switching between Base and
Device operation modes:
– To switch between Base and Device operation
modes, click the Icon symbol in the upper left
corner of the window.
Faders
The TC Icon software has large on-screen fad-
ers. They have several features that will help you
operate your UpCon efficiently.
– There are six on-screen faders.
– You can change the position of the faders or
hide them completely – see“UI page” on page
34.
– The name of the parameter that a fader is cur-
rently assigned to is displayed above the fad-
er.
– When no label is shown above a fader, that
fader is currently not assigned to a parameter.
– Fader assignments and values will always re-
flect the last Engine you have accessed.
Using Faders for fine adjustments
When a parameter is assigned to a fader, you
can choose between
Normal and Fine adjust-
ment mode.
– In Normal Adjustment mode, the fader range
will cover the full parameter range – e.g.
-18 dB to 18 dB for the Center Trim parameter.
– In Fine Adjustment mode, the fader range
will be smaller, allowing you to fine-tune
around the current value – e.g. in 0.1 dB steps
for a level parameter.
To switch a fader from Normal Adjustment mode
to Fine Adjustment mode or back, click the label
