6. Installation
PNEG-1095 FCDL 4.00" Corrugation Externally Stiffened Grain Bin 73
Parts for Transition Installation (TR-7048)
Figure 6AJ
Transition # Ref # Part # Description Qty
TR-7048 Parts Inventory
1 TR-7028 Top Panel 1
2 TR-6194 Sizing Angle 1
3 TR-7027 Bottom Panel 1
4 TR-6312 Entrance Collar Brace 3
5 TR-6476 Entrance Collar Mounting Bracket 2
6 TR-6196 Side Entrance Collar 2
7 TR-7029 Right Hand Side Panel 1
7 TR-7030 Left Hand Side Panel 1
8 TR-7031 Top Entrance Collar 1
PL-8078 Hardware Package 1
PL-8078 Parts Inventory
A S-275 5/16"-18 x 3/4" Bin Bolt 118
B S-277 5/16"-18 x 1-1/4" Bin Bolt 10
C S-396 5/16"-18 Hex Nut 128
D S-7621 #10-16 x 1" Self-Drilling Screw 20
