5. Foundations
PNEG-1095 FCDL 4.00" Corrugation Externally Stiffened Grain Bin 27
Diameter of Bin: 33'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 3 in. 2 17 ft. 3 in. 1700 1100 300 23
7, 8 1 ft. 11 in. 2 17 ft. 4 in. 1700 1100 300 25
9, 10 2 ft. 9 in. 3 17 ft. 6 in. 1700 1100 600 29
11, 12 3 ft. 10 in. 4 18 ft. 0 in. 1700 1100 800 34
Diameter of Bin: 36'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 3 in. 2 18 ft. 9 in. 2000 1300 300 26
7, 8 2 ft. 0 in. 2 18 ft. 11 in. 2000 1300 400 30
9, 10 2 ft. 10 in. 3 19 ft. 0 in. 2000 1300 600 33
11, 12 3 ft. 11 in. 4 19 ft. 6 in. 2000 1300 900 39
13 4 ft. 10 in. 5 19 ft. 9 in. 2000 1300 1100 43
Diameter of Bin: 42'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 4 in. 2 21 ft. 8 in. 2600 1800 300 34
7, 8 2 ft. 1 in. 3 21 ft. 11 in. 2600 1800 700 39
9 3 ft. 1 in. 4 22 ft. 2 in. 2600 1800 900 44
10, 11 4 ft. 2 in. 5 22 ft. 7 in. 2600 1800 1200 50
12, 13 4 ft. 10 in. 5 22 ft. 11 in. 2600 1800 1300 54
14 5 ft. 6 in. 6 23 ft. 2 in. 2600 1800 1500 66
Diameter of Bin: 48'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 5 in. 2 24 ft. 8 in. 3400 2300 400 44
7, 8 2 ft. 3 in. 3 24 ft. 11 in. 3400 2300 800 49
9 3 ft. 3 in. 4 25 ft. 2 in. 3400 2300 1100 55
10, 11 4 ft. 5 in. 5 25 ft. 8 in. 3400 2300 1400 63
12, 13 5 ft. 1 in. 5 25 ft. 11 in. 3400 2300 1500 67
14 5 ft. 8 in. 6 26 ft. 2 in. 3400 2300 1700 72
Diameter of Bin: 54'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 5 in. 2 27 ft. 9 in. 4800 3300 400 56
7, 8 2 ft. 3 in. 3 28 ft. 1 in. 4800 3300 600 63
9, 10 3 ft. 3 in. 4 28 ft. 4 in. 4800 3300 700 69
11, 12 4 ft. 5 in. 5 28 ft. 7 in. 4800 3300 1400 75
13, 14 6 ft. 0 in. 6 29 ft. 2 in. 4800 3300 1900 87
Diameter of Bin: 60'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 6 in. 2 30 ft. 7 in. 5400 3600 400 65
7, 8 2 ft. 10 in. 3 31 ft. 3 in. 5400 3600 1100 77
9, 10 3 ft. 8 in. 4 31 ft. 7 in. 5400 3600 1400 82
11, 12 4 ft. 7 in. 5 31 ft. 9 in. 5400 3600 1700 91
13 6 ft. 1 in. 6 32 ft. 4 in. 5400 3600 2200 103
