5. Foundations
26 PNEG-1095 FCDL 4.00" Corrugation Externally Stiffened Grain Bin
Frost Free Pads
(Refer Figure 5J on Page 25.)
Diameter of Bin: 12'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 0 in. 2 6 ft. 9 in. 300 200 100 5
7, 8 1 ft. 7 in. 2 6 ft. 9 in. 300 200 100 5
9, 10 2 ft. 0 in. 2 7 ft. 0 in. 300 200 200 6
Diameter of Bin: 15'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 0 in. 2 8 ft. 3 in. 400 300 100 6
7, 8 1 ft. 7 in. 2 8 ft. 3 in. 400 300 100 7
9, 10 2 ft. 0 in. 2 8 ft. 7 in. 400 300 200 8
Diameter of Bin: 18'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 0 in. 2 9 ft. 9 in. 500 400 200 8
7, 8 1 ft. 7 in. 2 9 ft. 9 in. 500 400 200 9
9 2 ft. 0 in. 2 10 ft. 1 in. 500 400 200 11
Diameter of Bin: 21'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 1 in. 2 11 ft. 3 in. 700 500 200 11
7, 8 1 ft. 7 in. 2 11 ft. 3 in. 700 500 200 12
9 2 ft. 0 in. 2 11 ft. 6 in. 700 500 300 13
Diameter of Bin: 24'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 1 in. 2 12 ft. 9 in. 900 600 200 13
7, 8 1 ft. 9 in. 2 12 ft. 9 in. 900 600 200 15
9, 10 2 ft. 6 in. 3 13 ft. 2 in. 900 600 400 18
Diameter of Bin: 27'
Corrugation: 4.00''
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18'' x 18'' Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 2 in. 2 14 ft. 3 in. 1100 800 200 16
7, 8 1 ft. 10 in. 2 14 ft. 4 in. 1100 800 200 18
9, 10 2 ft. 7 in. 3 14 ft. 7 in. 1100 800 500 21
Diameter of Bin: 30'
Corrugation: 4.00"
Ring # B N
Outside
Radius
Sq. Ft. Mesh
6 x 6 - 6/6
Optional #4**
18" x 18" Grid (ft.)
Length #6
Bar (ft.)
Total Cu. Yds.
Concrete
6 1 ft. 2 in. 2 15 ft. 9 in. 1400 900 200 19
7, 8 1 ft. 10 in. 2 15 ft. 10 in. 1400 900 200 21
9, 10 2 ft. 8 in. 3 16 ft. 1 in. 1400 900 500 25
11, 12 3 ft. 8 in. 4 16 ft. 5 in. 1400 900 700 29
