6. Installation
50 PNEG-1095 FCDL 4.00" Corrugation Externally Stiffened Grain Bin
FCDL Stiffeners
FCDL stiffeners will have an identifying part number stamped on the part.
* The XX in the part numbers at the bottom will identify the stiffener’s gauge.
Example: FC-4205714 is a 2 ring standard stiffener 14 gauge.
Stiffener Description Part # Overall Length Color Code
2 Ring 10 Gauge (Base) FC-4207210 94-27/32" Purple
2 Ring 12 Gauge (Base) FC-4207212 94-27/32" Black
2 Ring 14 Gauge (Base) FC-4207214 94-27/32" Green
2 Ring 16 Gauge (Base) FC-4207216 93-13/16" Blue
2 Ring 8 Gauge (Base) FC-4207308 88-3/16" Yellow
2 Ring 5 Gauge (Base) FC-42101 88-3/16" Yellow/Blue
2 Ring 5 Gauge FC-421005 87-15/16" Yellow/Blue
2 Ring 8 Gauge FC-4206308 87-15/16" Yellow
2 Ring 10 Gauge Transition FC-42062 94-19/32" Purple
2 Ring 12 Gauge FC-4205712 94-19/32" Black
2 Ring 14 Gauge FC-4205714 94-19/32" Green
2 Ring 16 Gauge FC-4207516 93-9/16" Blue
2 Ring 16 Gauge (Top) FC-4206516 85-9/16" Blue
1 Ring 12 Gauge FC-4205912 50-19/32" Black
1 Ring 14 Gauge FC-4205914 50-19/32" Green
1 Ring 16 Gauge FC-4207416 49-9/16" Blue
1 Ring Top 16 Gauge FC-4206616 41-7/16" Blue
Splice FC-42076 10-11/16"
