5. Foundations
PNEG-1095 FCDL 4.00" Corrugation Externally Stiffened Grain Bin 29
Inverted “T” Foundations
(See Figure 5K on Page 28.)
Diameter of Bin: 18'
Ring # B C D M N P #4 Bar (ft.) #5 Bar (ft.)
Cu. Yds.
Concrete
6 1'-3" 9'-8" 9'-8" 5 #4's 2 #5's #5 at 14" c/c 1600 300 18
7, 8 1'-7" 9'-8" 9'-10" 5 #4's 2 #5's #5 at 14" c/c 1600 300 19
9, 10 2'-2" 9'-8" 10'-1" 5 #4's 3 #5's #5 at 14" c/c 1600 300 20
11, 12 2'-4" 9'-8" 10'-2" 5 #4's 3 #5's #5 at 14" c/c 1600 300 21
Diameter of Bin: 21'
Ring # B C D M N P #4 Bar (ft.) #5 Bar (ft.)
Cu. Yds.
Concrete
6 1'-3" 11'-2" 11'-2" 5 #4's 2 #5's #5 at 14" c/c 2000 300 22
7, 8 1'-8" 11'-2" 11'-4" 5 #4's 2 #5's #5 at 14" c/c 2000 300 23
9, 10 2'-3" 11'-2" 11'-7" 5 #4's 3 #5's #5 at 14" c/c 2000 400 25
11, 12 2'-6" 11'-2" 11'-8" 5 #4's 3 #5's #5 at 14" c/c 2000 400 27
Diameter of Bin: 24'
Ring # B C D M N P #4 Bar (ft.) #5 Bar (ft.)
Cu. Yds.
Concrete
6 1'-3" 12'-8" 12'-8" 5 #4's 2 #5's #5 at 14" c/c 2300 300 26
7, 8 1'-9" 12'-8" 13'-1" 5 #4's 2 #5's #5 at 14" c/c 2300 300 27
9 2'-5" 12'-8" 13'-2" 5 #4's 3 #5's #5 at 14" c/c 2300 500 29
10, 11 2'-8" 12'-8" 13'-4" 5 #4's 3 #5's #5 at 14" c/c 2300 500 31
Diameter of Bin: 27'
Ring # B C D M N P #4 Bar (ft.) #5 Bar (ft.)
Cu. Yds.
Concrete
6 1'-3" 14'-2" 14'-2" 5 #4's 2 #5's #5 at 14" c/c 2600 300 31
7, 8 1'-10" 14'-2" 14'-5" 5 #4's 2 #5's #5 at 14" c/c 2600 400 33
9 2'-6" 14'-2" 14'-8" 5 #4's 3 #5's #5 at 14" c/c 2600 500 35
10, 11 3'-4" 14'-2" 15'-1" 5 #4's 4 #5's #5 at 14" c/c 2600 700 37
Diameter of Bin: 30'
Ring # B C D M N P #4 Bar (ft.) #5 Bar (ft.)
Cu. Yds.
Concrete
6 1'-3" 15'-8" 15'-8" 5 #4's 2 #5's #5 at 14" c/c 3000 300 36
7, 8 1'-11" 15'-8" 16'-0" 5 #4's 2 #5's #5 at 14" c/c 3000 400 39
9, 10 2'-7" 15'-8" 16'-3" 5 #4's 3 #5's #5 at 14" c/c 3000 500 42
11, 12 3'-6" 15'-8" 16'-10" 5 #4's 4 #5's #5 at 14" c/c 3000 700 44
13 3'-11" 15'-8" 17'-0" 5 #4's 4 #5's #5 at 14" c/c 3000 700 46
Diameter of Bin: 33'
Ring # B C D M N P #4 Bar (ft.) #5 Bar (ft.)
Cu. Yds.
Concrete
6 1'-4" 17'-1" 17'-1" 5 #4's 2 #5's #5 at 14" c/c 3400 400 40
7, 8 1'-11" 17'-1" 17'-4" 5 #4's 2 #5's #5 at 14" c/c 3400 500 42
9, 10 2'-8" 17'-1" 17'-8" 5 #4's 3 #5's #5 at 14" c/c 3400 600 45
11, 12 3'-8" 17'-1" 18'-2" 5 #4's 4 #5's #5 at 14" c/c 3400 800 48
13 4'-2" 17'-1" 18'-7" 5 #4's 4 #5's #5 at 14" c/c 3400 900 51
