5. Foundations
32 PNEG-1095 FCDL 4.00" Corrugation Externally Stiffened Grain Bin
Bolting Requirements
**For stiffener to sidewall quantities see stiffener hardware.
New Style FCDL Stiffener Hardware Splice connections are figured for
Per Splice
16 Gauge 6 S-7927 3/8" x 1" Hex Flanged
Splice Bolting
6 S-9373 3/8" Hex Nuts
(2 Stiffeners Per Sheet)
Stiffener to Sidewall Bolting
Per Sheet
[(22) S-275 Per Sheet] 22 S-275 5/16" x 3/4" Bin Bolt
[(22) S-396 Per Sheet] 22 S-396 5/16" Hex Nuts
Per Splice
14 Gauge 8 S-7927 3/8" x 1" Hex Flanged
Splice Bolting
8 S-9373 3/8" Hex Nuts
(2 Stiffeners Per Sheet) Per Sheet
[(22) S-275 Per Sheet] Stiffener to Sidewall Bolting 22 S-275 5/16" x 3/4" Bin Bolt
[(22) S-396 Per Sheet] 22 S-396 5/16" Hex Nuts
Per Splice
12 Gauge 8 S-7927 3/8" x 1" Hex Flanged
Splice Bolting
Stiffener to Sidewall Bolting
8 S-9373 3/8" Hex Nuts
(2 Stiffeners Per Sheet) Per Sheet
[(22) S-275 Per Sheet] 20 S-275 5/16" x 3/4" Bin Bolt
[(2) S-277 Per Sheet] 2 S-277 5/16" x 1-1/4" Bin Bolt
[(22) S-396 Per Sheet] 22 S-396 5/16" Hex Nuts
Transitionals Splice connections are figured for
Per Splice
12 Gauge to 10 Gauge 8 S-7927 3/8" x 1" Hex Flanged
Splice Bolting
8 S-9373 3/8" Hex Nuts
(2 Stiffeners Per Sheet)
Stiffener to Sidewall Bolting
Per Sheet
[(20) S-275 Per Sheet] 20 S-275 5/16" x 3/4" Bin Bolt
[(2) S-277 Per Sheet] 2 S-277 5/16" x 1-1/4" Bin Bolt
[(22) S-396 Per Sheet] 22 S-396 5/16" Hex Nuts
Per Splice
10 Gauge Transitional to 8 Gauge 12 S-7927 3/8" x 1" Hex Flanged
8 Gauge to 8 Gauge Splice Bolting
Stiffener to Sidewall Bolting
12 S-9373 3/8" Hex Nuts
Add (1) FC-42076 Per Connection Per Sheet
[(18) S-275 Per Sheet] 18 S-275 5/16" x 3/4" Bin Bolt
[(4) S-277 Per Sheet] 4 S-277 5/16" x 1-1/4" Bin Bolt
[(4) S-277 Per Sheet] 22 S-396 5/16" Hex Nuts
Per Splice
8 Gauge to 5 Gauge 12 S-7927 3/8" x 1" Hex Flanged
5 Gauge to 5 Gauge Bearing Splice Bolting
Add (1) FC-42076 Per Connection 12 S-9373 3/8" Hex Nuts
[(22) S-277 Per Sheet] Stiffener to Sidewall Bolting 22 S-277 5/16" x 1-1/4" Bin Bolt
5 Gauge Stiffener 22 S-396 5/16" Hex Nuts
New Style FCDL Sidewall Hardware ** Refer to Stiffener Sheets for Stiffener
20 Gauge to 15 Gauge
56 S-275 5/16" x 3/4" Bin Bolt
56 S-396 5/16" Hex Nuts
7 ft. S-4458 Caulking (24' Roll)
14 Gauge
68 S-275 5/16" x 3/4" Bin Bolt
68 S-396 5/16" Hex Nuts
7 ft. S-4458 Caulking (24' Roll)
11 Gauge to 13 Gauge
68 S-455 3/8" x 1" Bin Bolt
68 S-456 3/8" Hex Nut
7 ft. S-4458 Caulking (24' Roll)
