PHOTO 58
PHOTO 59
11. Install the new Rough Country coil spring into the stock location. Be sure the coil seats properly into the bottom coil
pocket. See PHOTO 57.
12. Insert the bushings and sleeves from 1770bag7 into the new rear track bar.
13. Using a 19mm socket and stock hardware, install the new rear track bar in the original frame mount. See PHOTO
58.
14. Using a 13mm wrench, install the upper sway bar link on the sway bar. See Photo 59.
15. Insert the sleeves in 1770bag11 in the eyelet and install using the supplied 12mm x 65mm Bolts & lock nuts. Tighten
using a 19mm socket. See Photo 59.
16. Using a 17mm socket and stock hardware, install the new rear shocks into the stock location
17. Install the new rear brake line bracket using the stock hardware and 3/8” bolts, washers and nuts from 1770bag5 as
shown in PHOTO 60.
18. Torque all hardware to specs at this time to ensure that everything is tight. Check for adequate clearance on all
repositioned brake lines.
19. Reinstall the wheels and lower vehicle the ground. Torque the lug nuts according to the wheel manufacturers
recommendations.
20. With the vehicle on the ground, install the new rear track bar in the original frame mount using a 19mm socket and
stock hardware.
PHOTO 57
PHOTO 60
