84-01 4.5” & 6”XJ CHEROKEE LONG ARM KIT
Thank you for choosing Rough Country for your suspension needs.
Rough Country recommends a certified technician installs this system. In addition to these instructions, professional
knowledge of disassemble/reassembly procedures as well as post installation checks must be known. Attempts to install
this system without this knowledge and expertise may jeopardize the integrity and/or operating safety of the vehicle.
Please read all the instructions before beginning the installation. Check the kit hardware against the parts list. Be sure
you have all the needed parts and understand where they go. Also please review the tools needed and make sure you
are confident about undertaking this installation. If you have any questions about the installation of this kit, call Rough
Country at 731-285-9000.
PRODUCT USE INFORMATION
As a general rule, the taller a vehicle is the easier it will roll. We strongly recommend that seat belts and shoulder
harnesses should be worn at all times. Avoid situations where a side rollover may occur.
Braking performance and capabilities are decreased when significantly larger/heaver tires and wheels are used. Take
this into consideration while driving. Also, speedometer recalibration is necessary when larger tires are installed.
Do not add, alter, or fabricate any factory or after-market parts which increase vehicle height over the intended height of
the Rough Country product purchased. Mixing component brands, lifts, voids all warranties. Rough Country makes no
claims regarding lifting devices and excludes any and all implied claims. We will not be responsible for any product that
is altered.
The 4.5” Long Arm Kit system was developed for 32x11.50x15 tire on 15 x 8 after market wheel with 3.75” of back spac-
ing. The 6” kit was developed for 33x12.50x15 tire on 15 x 8 after market wheel with 3.75” of back spacing. Due to the
inconsistency of vehicles when manufactured and the various options available, the amount of actual lift gained by this
lift kit will vary. On models outfitted with extra bolt-on equipment and accessories, Rough Country offers new coil spring
isolator pads made from polyurethane to boost ride height 3/4".
Please verify before installation rear axle tube diameter is 2 1/2” or 3”. Both sets are included with this kit to accommo-
date rear axle options of the vehicle.
This kit features Rough Country’s adjustable joint design. Adjustable end tool is included in kit.
Assemble the joints per the separate instruction sheet Part # 92RCJ120 provided
NOTICE TO DEALER AND VECHICLE OWNER
Any vehicle equipped with any Rough country product must have the “Warning to Driver” decal installed on the sun visor
or dash. The decal is to act as a constant reminder for whoever is operating the vehicle of its unique handling character-
istics. INSTALLING DEALER—It is your responsibility to install the warning decal and to forward these installation in-
structions on too the vehicle owner for review and to be kept in the vehicle for its service life.
92PERF1689
Jack Stands
Floor Jack
Transmission Jack or comparable jack
Wheel Chocks
T-55 Torque Bit
T-30 Torque Bit
13mm Socket / Wrench
14mm Socket / Wrench
15mm Socket / Wrench
17mm Socket / Wrench
18mm Socket / Wrench
19mm Socket / Wrench
21mm Socket / Wrench 1/2” Socket / Wrench
9/16” Socket / Wrench
3/4” Socket / Wrench
1 1/8’ Wrench
17/32” Drill Bit
25/32” Drill Bit
23/64” Drill Bit
Drill Motor
Torque Wrench
Brake Fluid
Catch Pan
TOOLS NEEDED: Torque Specs:
Size Grade 5 Grade 8
5/16” 15 ft/lbs 20 ft/lbs
3/8” 30 ft/lbs 35 ft/lbs
7/16” 45 ft/lbs 60 ft/lbs
1/2” 65 ft/lbs 90 ft/lbs
9/16” 95 ft/lbs 130 ft/lbs
5/8” 135 ft/lbs 175 ft/lbs
3/4” 185 ft/lbs 280 ft/lbs
Class 8.8 Class 10.9
12MM 55ft/lbs 75ft/lbs
14MM 85ft/lbs 120ft/lbs
16MM 130ft/lbs 165ft/lbs
18MM 170ft/lbs 240ft/lbs
