VEGA VEGAPULS 62 (≥ 2.0.0 - ≥ 4.0.0) Modbus and Levelmaster protocol Approval according to LPR radio standard - Manual (Page 72)

Register Name Register Number Type Note
Status 1300 DWord See Register 100
PV 1302 Primary Variable in Byte Order of Register 3000
SV 1304 Secondary Variable in Byte Order of Register 3000
TV 1306 Third Variable in Byte Order of Register 3000
QV 1308 Quarternary Variable in Byte Order of Register 3000
Status 1400 DWord See Register 100
PV 1402 Primary Variable in Byte Order CDAB
Status 1412 DWord See Register 100
SV 1414 Secondary Variable in Byte Order CDAB
Status 1424 DWord See Register 100
TV 1426 Third Variable in Byte Order CDAB
Status 1436 DWord See Register 100
QV 1438 Quarternary Variable in Byte Order CDAB
Status 2000 DWord See Register 100
PV 2002 DWord Primary Variable in Byte Order ABCD (Big Endian)
SV 2004 DWord Secondary Variable in Byte Order ABCD (Big Endian)
TV 2006 DWord Third Variable in Byte Order ABCD (Big Endian)
QV 2008 DWord Quarternary Variable in Byte Order ABCD (Big
Endian)
Status 2100 DWord See Register 100
PV 2102 DWord Primary Variable in Byte-Reihenfolge DCBA (Little
Endian)
SV 2104 DWord Secondary Variable in Byte-Reihenfolge DCBA (Little
Endian)
TV 2106 DWord Third Variable in Byte-Reihenfolge ABCD DCBA (Little
Endian)
QV 2108 DWord Quarternary Variable in Byte-Reihenfolge DCBA (Little
Endian)
Status 2200 DWord See Register 100
PV 2202 DWord Primary Variable in Byte Order BACD (Middle Endian)
72 VEGAPULS 62 • Approval according to LPR radio standard
10 Supplement
41722
-EN
-120706
