l
1 x closing cap ½ NPT, 1 x blind stopper
½
NPT, 1 x blind stopper M16 x 1.5 or
optionally 7) 1 x plug M12 x 1 for external
indicating and adjustment unit
or:
l
1 x plug (depending on the version), 1 x blind
stopper M20 x 1.5; 1 x blind stopper M16 x 1.5
or optionally
8) 1 x plug M12 x 1 for external
indicating and adjustment unit
Spring-loaded terminals for wire cross-section
-
Massive wire, cord 0.2 … 2.5 mm² (AWG 24 … 14)
-
Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
-
Two stranded wires with double end
sleeve, each 0.2 … 1.5 mm² (AWG 24 … 16)
Indicating and adjustment module
Voltage supply and data transmission through the sensor
Indication LC display in dot matrix
Measured value indication
-
Number of digits 5
-
Size of digits W x H = 7 x 13 mm (sensors with software ≥ 4.0.0,
hardware ≥ 2.0.0)
W x H = 5 x 8 mm (sensors with software ≤ 3.99,
hardware < 2.0.0)
Adjustment elements 4 keys
Protection rating
-
unassembled IP 20
-
mounted into the sensor without cover IP 40
Materials
-
Housing ABS
-
Inspection window Polyester foil
Integrated clock
Date format Day.Month.Year
Time format 12 h/24 h
Time zone Ex factory CET
Measurement electronics temerature
Resolution 1 °C (1.8 °F)
Accuracy ± 1 °C (1.8 °F)
7) Only with Ex d version
8) Only with Ex d version
