Product description
1 Product description
1.1 Function and configuration
VEGAMET 514V is a signal conditioning in-
strument for a number of applications, e.g.:
- level measurement
- gauge measurement
- process pressure measurement
- in addition temperature measurement (with
respective sensors)
- measurement with automatic correction
- etc.
Software configuration
Functional component
- measurement loop
TAG 1
PC/DCS components
- PC/DCS outputs
Input component
- VBUS input
- contact input
Output components
- current output
- voltage output
- DISBUS outputs
- failure output
- MET display
- relay outputs
Function
The signal conditioning instruments power
the connected sensors and process their
measuring data. The conditioning is done via
a special software consisting of functional
components (FB), input components (EB),
output components (AB) as well as DCS
components (PB).
Configuration
The VEGAMET 514V signal conditioning
instrument is constructed as a module card
in European size with 5 TE (= 25.4 mm)
width. The front plate contains an adjustment
module with LC display and keys. The front
plate of VEGAMET 514VN does not contain
an adjustment module.
EB FB
AB
PB
