Installation Guide
Power Monitoring
E51H2, E51H5
TM
Setting
Default Value*
BACnet Object
Setup Password
00000
n/a
Reset Password
00000
n/a
System Type
40 (3 + N) Wye
AV2
CT Primary Ratio
100A
AV3
CT Secondary Ratio
1V
AV4
PT Ratio
1:1 (none)
AV5
System Voltage
600 V L-L
AV6
Max. Theoretical Power
Calculated from AV2, AV3, AV5 & AV6 (with all default
settings, this would be 103.92 kW)
AI45
Display Mode
1 (IEEE Units)
AV7
Phase Loss Voltage Threshold
10% of System Voltage
AV8
Phase Loss Voltage Threshold
25% Phase to Phase Imbalance
AV9
Demand: number of subintervals per interval
1 (block mode)
AV10
Demand: sub-interval length
900 sec (15 min)
(AV11 default value is 90000 [1/100 seconds])
AV11
BACnet MAC Address
001
n/a
BACnet MS/TP Baud Rate
76.8 kBaud
n/a
BACnet MS/TP Max_Master
127
Device
BACnet Device_ID
Pseudo-random value
from 1,000,000 to 3,097,151
Device
BACnet Device Location
Installed location not yet identified
Device
Trend_Log Object 1
Log_Device_Object_Property **
AI2 (Real Energy Import)
TL1
Trend_Log Object 2
Log_Device_Object_Property **
AI3 (Real Energy Export)
TL2
Trend_Log Object 3
Log_Device_Object_Property **
AI19 (Total Real Power Present Demand)
TL3
* Default values are preset at the factory. Once changed, there is no way to automatically reset defaults. They must be restored individually. The baud rate and
MAC address are set through the user-interface screens, and the others are set by re-writing each Object (see BACnet Programming Information section, next
page).
** These values are available only on the E51H5. The E51H2 does not support the data logging functions.
BACnet Default
Settings
