Drawing & dimensions

Important notice

All VH7200 series controls are for use
as operating controls only and are not
safety devices. These instruments have
undergone rigorous tests and

verifications prior to shipment to ensure proper and
reliable operation in the field. Whenever a control
failure could lead to personal injury and/or loss of
property, it becomes the responsibility of the user /
installer / electrical system designer to incorporate
safety devices (such as relays, flow switch, thermal
protections, etc…) and/or alarm system to protect the
entire system against such catastrophic failures.

Tampering of the devices or miss application of the
device will void warranty.


Fig.16 – Humidistat dimensions : VH7200A1000, VH7270F1000, VH7270K1000




















































Fig.17 – Humidistat dimensions : VH7270D1000
