Super Single Tires / Offset Wheels
OFFSET WHEELS
Zero offset wheel
on standard
width axle
Outset wheel
on standard
width axle
Track
Track
Track
Inset wheel on
standard width
axle
Outset (positive) – The tire centerline is positioned outboard of the wheel
mounting face.
Inset (negative) – The tire centerline is positioned inboard of the wheel
mounting face.
Super Singles or Wide-Based Tires– Term associated with single tire drive
axle arrangements typically used with outset or zero offset wheels (in place of
dual tire arrangements).
