AXAG-0200 June 2009 14
Fi
re
S
ervice
Axle
Model
Max.
GAWR (lb)
Max.
SLR (in)
Engine Max. Gross Weight (lb)
( GVW )
Gear Ratios
HP Torque
(lb-ft)
Operation 1 Fastest Slowest
Single Axles
S14-110 13,500 16.5 330 550 24,500 3.73 5.13
S16-130 15,500 18.1 330 605 26,500 3.73 5.13
17060S 17,000 19.7 330 950 27,000 3.25 5.57
19060S 19,000 20.1 330 950 31,000 3.25 5.57
21060S 22,000 21.1 330 950 34,000 3.25 5.57
S21-170 22,000 21.1 450 1450 45,000 3.07 5.57
S21-170E 22,000 21.1 450 1450 45,000 3.07 5.57
22060S 22,000 21.1 330 950 34,000 3.25 5.57
S23-170 23,000 22.0 450 1450 45,000 3.07 5.57
S23-170E 23,000 22.0 450 1450 45,000 3.07 5.57
S23-190 24,000 22.0 525 1650 46,000 3.07 6.14
S23-190E 24,000 22.0 525 1650 46,000 3.42 6.14
S25-170 27,000 22.0 450 1450 49,000 3.07 5.57
S25-170E 27,000 22.0 450 1450 49,000 3.07 5.57
S26-190 27,000 22.0 525 1650 49,000 3.42 6.14
S26-190E 27,000 22.0 525 1650 49,000 3.42 6.14
S30-190 31,000 22.7 525 1650 53,000 3.42 6.14
S30-190E 31,000 22.7 525 1650 53,000 3.42 6.14
S30-590 31,000 22.7 525 1650 53,000 4.75 6.65
S35-590 35,000 22.7 525 1650 58,000 4.75 6.65
Tandem Axles
DS344 34,000 19.7 450 1450 56,000 3.25 5.57
DS404-(P) 40,000 21.1 500 1550 62,000 3.25 5.57
DS405-(P) 42,000 21.1 500 1550 64,000 3.25 5.57
DSH40-(P) 42,000 21.1 550 1850 64,000 3.25 4.88
D40-170 42,000 21.1 625 2050 64,000 3.21 5.57
DSH44-(P) 45,000 21.1 550 1850 67,000 3.25 5.29
D46-170 46,000 22.0 625 2050 68,000 3.21 5.57
D46-170H 50,000 22.0 625 2050 70,000 3.21 5.57
D50-170 52,000 22.0 625 2050 72,000 3.21 5.57
D52-190P 54,000 22.0 625 2050 76,000 3.42 5.38
D60-190P 60,000 22.7 625 2050 82,000 3.42 5.38
