Oil Field
1.
Suspension restrictions may exist with the D46-170. Please consult the Suspension Guideline Section for minimum
requirements.
2.
Allowable
gross axle weight rating (
) varies with axle ratio. Refer to Structural Rating Section for
additional information regarding permissible gross axle weight ratings.
Axle
Model
Max.
(lb)
Max.
SLR (in)
Engine
Max Gross Weight (lb)
/
)
Gear Ratios
Notes
HP
Torque
(lb-ft)
Operation
1
Operation
2
Fastest
Slowest
DS405-(P)
40,000
21.1
375
1450
100,000
3.55
5.29
DSH40-(P)
40,000
21.1
475
1650
100,000
3.55
4.88
D40-170
40,000
21.1
625
2050
120,000
100,000
3.42
5.38
DSH44-(P)
44,000
21.1
475
1650
72,000
72,000
3.55
5.29
DT463-P
46,000
22.0
600
1850
120,000
100,000
3.70/5.04 4.88/6.64
D46-170
46,000
22.0
625
2050
120,000
100,000
3.42
5.38
1
D46-170H
46,000
22.0
625
2050
120,000
100,000
3.42
5.38
D46-590HP
46,000
22.0
625
2050
140,000
120,000
4.75
6.65
D50-170
50,000
22.0
625
2050
120,000
100,000
3.42
5.38
D52-190P
52,000
22.0
625
2050
140,000
120,000
3.42
5.38
D52-590P
52,000
22.0
625
2050
140,000
120,000
4.75
6.65
D60-190P
60,000
22.7
625
2050
140,000
120,000
3.42
5.38
D60-590P
60,000
22.7
625
2050
140,000
120,000
4.75
6.65
D70-590P
70,000
22.7
625
2050
140,000
120,000
4.75
6.65
T60-174
19.7
450
1650
100,000
80,000
2
TDT583-P
58,000
20.1
600
1850
120,000
100,000
3.90/5.31 4.88/6.64
2
T69-170HP
58,000
20.7
625
2050
120,000
100,000
3.91
4.78
2
T78-190P
58,000
20.7
625
2050
140,000
120,000
3.91
4.78
2
T78-590P
58,000
20.7
625
2050
140,000
120,000
4.75
7.30
