AXAG-0200 June 2009 58
35,000 lb. Housing Structural Ratings
Housing Dimensions
Drive Axle Model
(Nominal GAWR
(See Note 1)
- 35,000 lb.)
Housing Box Section
(H x W x T)
Spindle Diameters
(Inner/Outer)
Spindle
Type
Standard Track Wide Track
S35-590 6.75 x 5.63 x .88 6.75 x 5.63 x .88 4.125/3.500 W
Gross Axle Ratings Based on the Use of Wide Track Housings (lb.)
Housing Box Section (in.)
75 in.Track
Width
80 in.Track
Width
85 in.Track
Width
Notes
6.75 x 5.63 x .88 35,000 35,000 35,000 2
Gross Axle Ratings Based on the Use of Outset Single Wheels (lb.)
Housing Box Section (in.) 78 in. Maximum Track Width 80 in. Maximum Track Width Notes
6.75 x 5.63 x .88 Not Approved Not Approved 3
Gross Axle Rating Based on Site Travel Conditions Only (lb.) (See Note 4)
Housing Box Section (in.)
72 in.Track
(Standard)
78 in.Track
(Single Wheels)
80 in. Track
(Single Wheels)
Notes
6.75 x 5.63 x .88 40,000 Not Approved Not Approved 3
Notes:
1. Nominal gross axle weight rating is based on minimum axle mounting centers of 38 in. and a maximum
track width of 72 in.
2. Track widths are nominal and may vary with wheel equipment.
3. The S35-590 is not approved with single outset wheels .
4. Site Travel : 5 miles per hour maximum speed with liftable axles raised. This condition should not exceed
5% of the total operating miles of the vehicle.
