23,000 lb. Housing Structural Ratings
Housing Dimensions
Drive Axle Model
(Nominal GAWR
(See Note 1)
- 23,000 lb.)
Housing Box Section
(H x W x T)
Spindle Diameters
(Inner/Outer)
Spindle Type
Standard Track Wide Track
23082T 5.24 x 4.61 x .50 5.24 x 4.61 x .56 3.750 / 3.250
R
S23-170 5.24 x 4.61 x .43 5.24 x 4.61 x .63 3.750 / 3.250
S23-190, S23-590 5.24 x 4.61 x .50 5.24 x 4.61 x .63 3.750 / 3.250
Gross Axle Ratings Based on the Use of Wide Track Housings (lb.)
Housing Box Section (in.) 78 in Maximum Track Width Notes
5.24 x 4.61 x .56 22,000 2
5.24 x 4.61 x .63 23,000 2
Gross Axle Ratings Based on the Use of Outset Single Wheels (lb.) (See Note 5)
Housing Box Section (in.) 78 in. Maximum Track Width 80 in. Maximum Track Width Notes
5.24 x 4.61 x .43 18,000 16,000 3
5.24 x 4.61 x .50 20,000 18,000 3
Gross Axle Rating Based on Site Travel Conditions Only (lb.)
(See Note 4)
Housing Box Section (in.)
73 in. Track
(Standard)
78 in. Track
(Single Wheels)
80 in. Track
(Single Wheels)
Notes
5.24 x 4.61 x .43 29,000 24,000 22,000 3
5.24 x 4.61 x .50 30,000 27,000 25,000 3
Notes:
1. Nominal gross axle weight rating is based on minimum axle mounting centers of 38 inch and a maximum
track width of 72 in.
2. Track widths are nominal and may vary with wheel equipment.
3. All ratings are for standard track width housings. Track increase over standard is produced by wheel
outset .
4. Site Travel : 5 miles per hour maximum speed with liftable axles raised. This condition should not exceed
5% of the total operating miles of the vehicle.
5. The usage of single tires on single drive axles may be prohibited by the tire manufacturer. The tire
manufacturer may also limit the rating of the tire based on the load per tire and the pressure, which could
be less than the approved axle rating.
