Spicer Drive Axles Application Guidelines - Manual (Page 7)

AXAG-0200 June 2009 7
City Delivery
1
. Suspension restrictions may exist with the DS404-(P). Please consult the Housing Structural Ratings Section for
minimum housing box section requirements.
Axle
Model
Max.
GAWR
(lb)
Max.
SLR (in)
Engine Max. Gross Weight (lb)
( GVW / GCW )
Gear Ratios Notes
HP Torque
(lb-ft)
Operation
1
Operation
2
Operation
3
Fastest Slowest
Single Axles
S14-110 13,500 16.5 325 560 23,000 23,000 N/A 3.73 5.38
S16-130 15,500 18.1 325 605 25,000 25,000 N/A 3.73 5.38
17060S 17,000 19.7 300 860 60,000 50,000 45,000 3.08 5.57
19060S 19,000 20.1 300 860 60,000 50,000 45,000 3.08 5.57
19055T 19,000 20.1 300 860 60,000 55,000 50,000 3.90/5.32 5.57/7.60
21060S 21,000 21.1 300 860 60,000 50,000 45,000 3.08 5.57
21065T 21,000 21.1 300 860 60,000 55,000 50,000 3.90/5.32 5.57/7.60
S21-170 21,000 21.1 400 1450 80,000 65,000 55,000 3.07 5.57
S21-170E 21,000 21.1 400 1450 80,000 65,000 55,000 3.07 5.57
22060S 22,000 21.1 300 860 60,000 50,000 45,000 3.08 5.57
22065T 22,000 21.1 300 860 60,000 55,000 50,000 3.90/5.32 5.57/7.60
23082T 23,000 22.0 400 1450 80,000 65,000 55,000 3.70/5.04 5.43/7.39
S23-170 23,000 22.0 400 1450 80,000 65,000 55,000 3.07 5.57
S23-170E 23,000 22.0 400 1450 80,000 65,000 55,000 3.07 5.57
S23-190 23,000 22.0 475 1650 100,000 85,000 70,000 3.07 5.57
S23-190E 23,000 22.0 475 1650 100,000 85,000 70,000 3.07 5.57
S25-170 25,000 22.0 400 1450 80,000 65,000 55,000 3.07 5.57
S25-170E 25,000 22.0 400 1450 80,000 65,000 55,000 3.07 5.57
26082T 26,000 22.0 400 1450 80,000 65,000 55,000 3.70/5.04 5.43/7.39
S26-190 26,000 22.0 475 1650 100,000 85,000 70,000 3.42 5.57
S26-190E 26,000 22.0 475 1650 100,000 85,000 70,000 3.42 5.57
Tandem Axles
DS344 34,000 19.7 430 1550 90,000 90,000 80,000 3.08 5.57
DS404-
(P)
40,000 21.1 475 1650 90,000 90,000 80,000 3.08 5.57 1
DS405-
(P)
40,000 21.1 475 1650 90,000 90,000 80,000 3.08 5.57
DSH40-
(P)
40,000 21.1 550 1850 90,000 90,000 80,000 3.08 4.88
D40-170 40,000 21.1 550 1850 120,000 120,000 100,000 3.07 5.38
