Tridem Structural Ratings
(cont’d)
Dana T60-174
Ratio GAWR Rating
78” WT 78” Track 80” Track
Housing Single Tire Single Tire
3.36 44,000 44,000 44,000 44,000
3.55 46,000 46,000 46,000 46,000
3.70 48,000 48,000 48,000 48,000
3.90 51,000 51,000 51,000 50,000
4.11 53,000 53,000 53,000 50,000
4.33 56,000 54,000 54,000 50,000
4.63 60,000 54,000 54,000 50,000
5.29 60,000 54,000 54,000 50,000
5.57 59,000 54,000 54,000 50,000
6.17 59,000 54,000 54,000 50,000
7.17 53,000 53,000 53,000 50,000
Dana T69-170HP
Ratio GAWR Rating
78” WT 78” Track 80” Track
Hsg Single Tire Single Tire
3.42 51,000 51,000 51,000 51,000
3.58 53,000 53,000 53,000 53,000
3.73 55,000 55,000 55,000 55,000
3.91 58,000 58,000 58,000 58,000
4.10 61,000 61,000 61,000 61,000
4.30 64,000 64,000 64,000 64,000
4.56 68,000 68,000 68,000 66,000
4.78 67,000 67,000 67,000 66,000
5.25 69,000 69,000 69,000 66,000
5.38 69,000 69,000 69,000 66,000
5.57 69,000 69,000 69,000 66,000
6.14 69,000 69,000 69,000 66,000
6.83 66,000 66,000 66,000 66,000
7.17 69,000 69,000 69,000 66,000
Dana T78-190P
, T78-590P
Ratio GAWR Rating
78” WT 78” Track 80” Track
Hsg Single Tire Single Tire
3.42 51,000 51,000 51,000 51,000
3.58 53,000 53,000 53,000 53,000
3.73 55,000 55,000 55,000 55,000
3.91 58,000 58,000 58,000 58,000
4.10 61,000 61,000 61,000 61,000
4.30 64,000 64,000 64,000 64,000
4.56 68,000 68,000 68,000 66,000
4.78 71,000 71,000 71,000 71,000
5.25 78,000 78,000 78,000 72,000
5.38 78,000 78,000 78,000 72,000
5.57 78,000 78,000 78,000 72,000
6.14 78,000 78,000 78,000 72,000
6.83 77,000 77,000 77,000 72,000
7.17 71,000 71,000 71,000 71,000
