EN-8 CKW Serial Interface Option Kit
TABLE 1. SERIAL INTERFACE COMMAND TABLE.
Command Description
Character
PU Print current weighing unit: kg, g, lb, oz, lb:oz, %.
P Same as pressing PRINT button.
T Same as pressing TARE button.
Z Same as pressing ZERO button.
xS Enable print stable data only. Where x=0 for Off, x=1 for On.
xP Auto print condition. Where x = 1 to 3600 second intervals,
x=0 for Off, x=C for Continuous, x=S for On Stable.
xCM Checkweigh Input Mode, where x=0 for Range, 1=Variance,
2=Percent (%).
xCU Set Under value, as a Range, Variance or Percent value
(depending on Checkweigh Input Mode setting).*
xCO Set Over value, as a Range, Variance or Percent value
(depending on Checkweigh Input Mode setting).*
xCT Set Target value (used only in Variance and Percent Input
Modes, not used in range Mode)*.
xU Set weighing unit: Where x=1 to 6, 1=g, 2=kg, 3=lb, 4=oz,
5=lb:oz, 6=%, if x=blank, then increment to next available
mode. (The unit can not be selected if it is not enabled).
PV Print model name, software revisions, and LFT status - if on, (eg.
“CKW-55 Sr1.28 RS485 Sr1.25”
xT Set a pre-set tare value of x, in present weighing units*
* Up to 6 numeric characters, an optional “-” sign, and single decimal point
(e.g., 1.000CU, 2:3.2CU) Use colon “:” as a separator for lb:oz data entry.
Note: All commands must be followed by a carriage return, , or carriage
return-line feed, , sequence. For addressed RS485 communication, all
commands must be preceded by the “@” character and a two digit address.
