Page 51
IT-10
Kit opzionale per l'interfaccia seriale CKW
APPENDICE A
Connessioni RS485 tipiche
Figura A.1 Tipica connessione duplex a 4 fili.
Figura A.2. Tipica connessione Half Duplex a 2 fili (W1 cortocircuitato).
Linee di trasmissione
a doppino
Linee di ricezione a
doppino
Massa
Collegare Tx+ a Rx+
Collegare Tx- a Rx-
Linee di ricezione/
trasmissione a doppino
Massa
6 TEXT-IT.pmd
1/28/2005, 11:10 AM
10
