Page 31
FR-10
Kit d’option d’interface série CKW
ANNEXE A
Connexions type de RS485
Figure A.1. Connexions duplex à 4 fils type.
Figure A.2. Connexions semi-duplex à 2 fils type (W1 court-circuité).
Lignes de transmission
à paire torsadée
Lignes de réception
à paire torsadée
Terre
Connexion TX+ à RX+
Connexion TX- à RX-
Lignes de réception/
de transmission
à paire torsadée
Terre
4 TEXT-FR.pmd
1/28/2005, 11:10 AM
10
