Page 21
ES-10
Kit opcional de interfase serial CKW
APÉNDICE A
Conexiones RS485 típicas
Figura A.1. Conexión dúplex de 4 cables típica.
Figura A.2. Conexión semi-dúplex de 2 cables típica. (W1 en corto).
Líneas de transmisión
de pares trenzados
Líneas de recepción
de pares trenzados
Tierra
Tierra
Conecte TX+ a RX+
Conecte TX- a RX-
Líneas de recepción/transmisión
de pares trenzados
3 TEXT-ES.pmd
1/28/2005, 11:10 AM
10
